Geotechnical Earthquake engineering design plays a crucial role in ensuring the safety and stability of infrastructure, buildings and communities in seismic prone areas. With the increasing frequency and magnitude of earthquakes, it is more important than ever to have advanced tools and systems to evaluate the seismic response of soil and rock formations. The GCTS SRC-100 Soil Resonant Column and Dynamic Soil Triaxial Testing System provides the ability to conduct advanced geotechnical earthquake engineering studies and assessments.
The SRC-100 system is a fully automated testing platform that can simulate the dynamic response of soil and rock formations to seismic loads, providing a realistic representation of in-situ soil behavior. The system can perform resonant column tests, dynamic triaxial tests and cyclic triaxial tests, providing a comprehensive understanding of soil behavior under cyclic and seismic loading conditions.
The resonant column test is a widely recognized method for determining the fundamental dynamic properties of soil and rock formations, including the shear modulus and damping ratio. The dynamic triaxial test, on the other hand, provides a more advanced evaluation of soil behavior under axial and cyclic loading conditions, including the evaluation of strength, stiffness, and failure mechanisms.
The SRC-100 system is designed to perform high-precision, high-accuracy testing in accordance with the most recent international standards and guidelines. The system features advanced hardware and software components that allow for precise control of the test conditions, as well as real-time data acquisition and analysis. This ensures that the results obtained from the system are accurate and reliable, and can be used to make critical design decisions.
The GCTS Soil Resonant Column and Dynamic Soil Triaxial Testing System combine the features of both resonant column and torsional shear devices into one elegant system. This enables them to evaluate the effects of a number of soil parameters, such as void ratio, confining pressure, strain amplitude, number of load cycles on shear modulus and material damping. By utilizing all available options, this system is capable of the full spectrum of modulus measurement, ranging from ultra-low strains to high strains with significant overlap.
For the resonant column test, a torsional drive is used to vibrate the top of the soil specimen at first-mode resonance at frequencies of up to 500 Hz while the bottom is fixed. A non-contacting rotational transducer is attached to the top platen monitor the torsional motion directly. The non-contacting sensor is located on extended arms to amplify the rotational deformation and provides a shear strain resolution of 10-6. An optional accelerometer can also be installed to measure large shear strains. These systems can also perform closed-loop torsional shear tests (stress or strain controlled) on the same soil specimen, either statically or dynamically, at up to 50 Hz.
With these systems, soil specimens can be tested under isotropic (hydrostatic) or anisotropic conditions. The driving and measuring system are mounted on a “floating” frame, which allows large vertical specimen deformations throughout the complete test. Its unique configuration also allows for very large shear deformations of up to ±20°.
ASTM D4015 Standard Test Methods for Modulus and Damping of Soils by Fixed-Base Resonant Column Devices
ASTM D7608 Standard Test Method for Torsional Ring Shear Test
